Power windows circuit for Mazda 6 GH (2007-2009)

AUTO BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLU WIRE BRN WIRE CLOSE CLOSE RELAY CONJUNCTION CIRCUIT DRIVER'S SIDE POWER WINDOW MOTOR (IN LEFT FRONT DOOR) GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY WIRE HALL EFFECT HALL EFFECT SWITCH 2 HOT AT ALL TIMES PWIND FUSE JC-03 LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR POWER WINDOW SUB SWITCH LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BLOCK (MAIN FUSE, RELAY BOX) (ON LEFT FRONT INNER FENDER PANEL) MIRRORS SYSTEM OPEN CLOSE OPEN RELAY P/W CM POWER WINDOW MAIN SWITCH POWER-CUT SWITCH RED WIRE RED/YEL WIRE RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR) RIGHT REAR POWER WINDOW SUB SWITCH SWITCH 1 VIO WIRE WHT WIRE YEL WIRE

AUTO BLK/YEL WIRE CLOSE CLOSE RELAY GRN WIRE GRN/YEL WIRE HALL EFFECT SWITCH 1 HALL EFFECT SWITCH 2 LT GRN/BLK WIRE LT GRN/RED WIRE OPEN RELAY P/W CM PASSENGER'S SIDE POWER WINDOW MOTOR (IN RIGHT FRONT DOOR) PASSENGER'S SIDE POWER WINDOW SUBSWITCH RED WIRE RED/YEL WIRE VIO WIRE YEL WIRE
