Mazda 6 GH (2007-2009) Computer data lines circuit

0740-215 2.3L 3.0L 3.0L AF CAN-L AG PNK CAN-H WIRE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) BRN WIRE CAN L CAN-H CLIMATE CONTROL UNIT (AUTOMATIC A/C) CONTROL MODULE (TCM) D-02 DATA LINK CONNECTOR 2 (UNDER LOWER LEFT SIDE OF DASH) DSC HYDRAULIC CONTROL MODULE (DSC HU/CM) (RIGHT FRONT CORNER OF ENGINE COMPT) FUEL PUMP RELAY (ON FUSE BLOCK) FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRY WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER JC-02 LT GRN WIRE LT GRN/BLK WIRE PCM (BEHIND LEFT SIDE OF DASH) PNK CAN-H WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND LEFT SIDE OF DASH) RED WIRE ROOM FUSE TIRE PRESSURE MONITORING SYSTEM CONTROL MODULE (IF EQUIPPED) VIO WIRE VIO/YEL WIRE W/ ABS W/ TRACTION CONTROL W/0 TRACTION CONTROL YEL/BLK WIRE
