Mazda 6 GH (2007-2009) mag fuse fan 1 fuse fan 2 fuse Wiring diagram

A/C FUSE AIR INTAKE ACTUATOR (BEHIND RIGHT SIDE OF DASH) AIR MIX ACTUATOR (BEHIND RIGHT SIDE OF DASH) AIRFLOW MODE ACTUATOR (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER FUSE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER RELAY (ON FUSE BLOCK) BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN/RED WIRE BRN/YEL WIRE CHECK CONNECTOR (UNDER RIGHT SIDE OF DASH) CLIMATE CONTROL UNIT/ HAZARD WARNING SWITCH DEF ENG BB FUSE EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON HOT W/ MAIN RELAY ENERGIZED JC-01 LT GRN WIRE LT GRN/RED WIRE MAG FUSE FAN 1 FUSE FAN 2 FUSE MAIN FUSE BLOCK (MAIN FUSE, RELAY BOX) (ON LEFT FRONT INNER FENDER PANEL) NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PWM UNIT (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/WHT WIRE ROOM FUSE SOLAR RADIATION SENSOR (TOP LEFT SIDE OF DASH) VENT VIO WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
