Mazda 6 GH (2007-2009) interior air lights conditioning system system Wiring diagram
This page shows the only wiring diagram for the component.interior air lights conditioning system system, which is found in the car Mazda 6 GH (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior air lights conditioning system system (1 of 1)
ABS FUSE
ACCESSORY SOCKET
AD FAN FUSE (2.3L) FAN 2 FUSE (3.0L)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
AUDIO FUSE
BLK WIRE
BLOWER FUSE
BLU WIRE
BRN WIRE
CIGAR FUSE
COOLING FANS SYSTEM
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
FAN FUSE (2.3L) FAN 1 FUSE (3.0L)
FOG FUSE
FROM BTN FUSE (DIAGRAM 1 OF 2)
FROM IG
FROM IGNITION SWITCH ACC (DIAGRAM 1 OF 2)
GRN WIRE
HEADLIGHTS EXTERIOR SYSTEM LIGHTS SYSTEM
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM TAIL FUSE
HEADLIGHTS, INTERIOR LIGHTS, WARNING SYSTEMS
ILLUMI FUSE
INSTRUMENT CLUSTER SYSTEM
INTERIOR AIR LIGHTS CONDITIONING SYSTEM SYSTEM
LT GRN WIRE
MAG FUSE FUSE (3.0L)
MAIN FUSE BLOCK
MIRROR FUSE
NAVIGATION MIRRORS DOOR SYSTEM SYSTEM LOCKS SYSTEM
ORG/ WIRE
PNK WIRE
PWR SEAT FUSE
R CIGAR FUSE METER ACC FUSE
REAR ACCESSORY SOCKET
REAR WINDOW DEFROSTER RELAY
RED WIRE
ROOM FUSE D LOCK FUSE
SEATS SYSTEM
SOUND SYSTEMS
TNS RELAY
W/ ADVANCED KEYLESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> INTERIOR AIR LIGHTS CONDITIONING SYSTEM SYSTEM
