Wiring diagram hot in on or start meter fuse (1 of 2)
2.3L 3.0L
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
CHARGE IND
COMPUTER DATA LINES SYSTEM
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GENERATOR
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START METER FUSE
INSTRUMENT CLUSTER
MAIN FUSE
MAIN FUSE BLOCK (MAIN FUSE, RELAY BOX) (ON LEFT FRONT INNER FENDER PANEL)
MICROCOMPUTER
NCA WIRE
PCM (BEHIND LEFT SIDE OF DASH)
RED WIRE
STARTING CIRCUIT
YEL/RED WIRE
Go to component -> Charging circuit -> HOT IN ON OR START METER FUSE
Wiring diagram hot in on or start meter fuse (2 of 2)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU ORG WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
FUSE BLOCK
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
HI AUTOSTOP SWITCH CIRCUIT BREAKER LO
HOT IN ON
HOT IN ON OR START METER FUSE
INSTRUMENT CLUSTER
INT (VOLUME)
INTERMITTENT WIPER RELAY
J/C-09
JC-01
OFF
OFF INT
ONE TOUCH
WASHER IND
WASHER SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
WIPER SWITCH
YEL BLK/ WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Front wiper/washer circuit -> HOT IN ON OR START METER FUSE
