Mazda 6 GH (2007-2009) door locks system supplemental restraints system power windows system Wiring diagram

A/C FUSE D LOCK FUSE R WIP FUSE AIR CONDITIONING SYSTEM DOOR LOCKS SYSTEM WIPER/WASHER SYSTEM ANTI-LOCK BRAKES SYSTEM BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM POWER WINDOWS SYSTEM ENGINE CONTROLS SYSTEM EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HAZARD FUSE HEADLIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM HORNS SYSTEM EXTERIOR LIGHTS SYSTEM ANTI-THEFT SYSTEM HOT AT ALL TIMES HOT IN ON HOT IN ON OR START INSTRUMENT CLUSTER SYSTEM INSTRUMENT CLUSTER SYSTEM HEADLIGHTS SYSTEM J/C 3 JC-02 LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL) METER FUSE NAVIGATION SYSTEM ORG/ WIRE PNK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SAS FUSE ROOM FUSE SOUND SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE VIO/WHT WIRE W/ REAR WIPER WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
