Mazda 6 GH (2007-2009) body control module (behind left kick panel) Wiring diagrams
This page contains all the electrical diagrams for the component. body control module (behind left kick panel), in which he is found in the car Mazda 6 GH (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
body control module (behind left kick panel) wiring diagram (1 of 3)
2.3L A/T
3.0L A/T
AUTO DIMMING MIRROR
BACKUP LIGHT RELAY (IN MAIN FUSE, RELAY BOX)
BACKUP LIGHT SWITCH (ON TRANSAXLE
BLK WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT BACKUP LIGHT
M/T
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
RED WIRE
RED/YEL WIRE
RIGHT BACKUP LIGHT
ROOM FUSE
TCM (BEHIND LEFT SIDE OF DASH)
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANSAXLE)
YEL WIRE
Go to component -> Backup lamps circuit -> BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
body control module (behind left kick panel) wiring diagram (2 of 3)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
BRN WIRE
CARGO COMPARTMENT LIGHT
CARGO COMPARTMENT LIGHT SWITCH
DOOR
FRONT MAP LIGHT
HATCHBACK/ WAGON
HOT AT ALL TIMES FUSE ROOM FUSE BLOCK (UNDER LEFT SIDE OF DASH)
JC-03
LEFT COURTESY LIGHT
LEFT VANITY MIRROR ILLUM
NCA WIRE
OFF
REAR MAP LIGHT
RED WIRE
RIGHT COURTESY LIGHT
RIGHT VANITY MIRROR ILLUM
SEDAN
TRUNK COMPARTMENT LIGHT
TRUNK COMPARTMENT LIGHT SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit -> BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
body control module (behind left kick panel) wiring diagram (3 of 3)
AUTO LIGHT-OFF CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
BRAKE SWITCH 2 (ON BRAKE PEDAL ASSEMBLY)
BRN WIRE
BRN/RED WIRE
CAPACITOR
CAPACITOR (SPORT WAGON)
DOOR LOCKS SYSTEM
EXCEPT 5 DOOR 5 DOOR
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HEAD
HEADLIGHT SWITCH
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT (REAR SPOILER)
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE BLOCK (ON LEFT HAZARD FUSE FRONT INNER FENDER PANEL)
HOT IN ACC OR RUN
HOT IN ON OR START
INSTRUMENT CLUSTER
JC-01
LEFT BRAKE LIGHT
LEFT FRONT COMBINATION LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN LIGHT
LEFT LICENSE PLATE LIGHT RIGHT TAILLIGHT (INBOARD COMBINATION LIGHT)
LEFT PARKING LIGHT
LEFT TAILLIGHT (INBOARD COMBINATION LIGHT)
LEFT TURN IND
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MAIN FUSE
METER ACC FUSE
METER FUSE
NCA WIRE
OFF TNS
ORG/ WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT BRAKE LIGHT
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING LIGHT
RIGHT REAR TURN LIGHT LEFT REAR TURN LIGHT
RIGHT TAILLIGHT (REAR COMBINATION LIGHT) LEFT TAILLIGHT (REAR COMBINATION LIGHT)
RIGHT TURN IND
ROOM FUSE
STOP FUSE
TAIL FUSE
TNS RELAY
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
