Mazda 6 GH (2007-2009) blu org wiring diagram
This page shows the only wiring diagram for the component.blu org, which is found in the car Mazda 6 GH (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
blu org wiring diagram (1 of 1)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU ORG WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
FUSE BLOCK
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
HI AUTOSTOP SWITCH CIRCUIT BREAKER LO
HOT IN ON
HOT IN ON OR START METER FUSE
INSTRUMENT CLUSTER
INT (VOLUME)
INTERMITTENT WIPER RELAY
J/C-09
JC-01
OFF
OFF INT
ONE TOUCH
WASHER IND
WASHER SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
WIPER SWITCH
YEL BLK/ WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Front wiper/washer circuit -> BLU ORG WIRE
