Car Wiring Diagrams for Anti-lock brakes circuit, with dynamic stability control for Mazda 6 GG facelift (2005-2008)

AA AB AC AD AE AF AG AH BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/YEL WIRE CHECK CONNECTOR (IN MAIN FUSE, RELAY BOX) COMBINED SENSOR (UNDER CENTER CONSOLE) COMPUTER DATA LINES SYSTEM DSC HYDRAULIC UNIT/CONTROL MODULE (DSC HU/CM) DSC IND DSC OFF IND DSC OFF SWITCH FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRY/RED WIRE HOT AT ALL TIMES ABS FUSE HOT IN ON OR START ILL INSTRUMENT CLUSTER JC G-02 LEFT FRONT ABS WHEEL SPEED SENSOR (LEFT SIDE OF ENGINE COMPT) LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE BLOCK (MAIN FUSE, RELAY BOX) (ON LEFT FRONT INNER FENDER PANEL) METER FUSE MICRO COMPUTER NCA WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR (RIGHT SIDE OF ENGINE COMPT) RIGHT REAR ABS WHEEL SPEED SENSOR (AT RIGHT REAR WHEELWELL) SAS FUSE VIO WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE
