2.3l turbo, automatic a/c circuit for Mazda 6 GG facelift (2005-2008)

A/C FUSE AIR INTAKE ACTUATOR (BEHIND RIGHT SIDE OF DASH) AIR MIX ACTUATOR AIRFLOW MODE ACTUATOR (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER FUSE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER RELAY (ON FUSE BLOCK) BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN/RED WIRE BRN/YEL WIRE CHECK CONNECTOR (UNDER RIGHT SIDE OF DASH) CLIMATE CONTROL UNIT COLD DEF ENG BB FUSE FAN 1 FUSE FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/BLK WIRE HOT HOT AT ALL TIMES HOT IN ON HOT W/ MAIN RELAY POWER ENERGIZED INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM LT GRN WIRE LT GRN/RED WIRE MAG FUSE FAN 2 FUSE MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL) ORG/ WIRE PNK WIRE PNK/BLK WIRE POWER METAL OXIDE SEMICONDUCTOR FIELD EFFECT TRANSISTOR RED WIRE RED/WHT WIRE ROOM FUSE SOLAR RADIATION SENSOR (TOP LEFT SIDE OF DASH) VENT VIO WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

A/C RELAY (IN MAIN FUSE, RELAY BOX) A/C WATER TEMPERATURE SENSOR (BEHIND LEFT SIDE OF DASH) AMBIENT TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT) BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COOLING FAN MOTOR 1 (AT LEFT FRONT OF ENGINE COMPARTMENT) COOLING FAN MOTOR 2 (AT RIGHT FRONT OF ENGINE COMPARTMENT) COOLING FAN RELAY (IN MAIN FUSE, RELAY BOX) ENGINE COOLANT TEMPERATURE SENSOR EVAPORATOR TEMPERATURE SENSOR (BEHIND CENTER OF DASH) FAN CONTROL MODULE (BEHIND LEFT SIDE OF FRONT GRILLE) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE JC-02 LT GRN/BLK WIRE MAGNETIC CLUTCH (LEFT FRONT OF ENGINE) MID NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT TEMPERATURE SENSOR (BEHIND LEFT SIDE OF DASH) POWERTRAIN CONTROL MODULE (PCM) (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/WHT WIRE VIO/GRN WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
