Mazda 6 GG facelift (2005-2008) center panel Wiring diagrams
This page contains all the electrical diagrams for the component. center panel, in which he is found in the car Mazda 6 GG facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
center panel wiring diagram (1 of 3)
AD FAN FUSE FAN FUSE
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CENTER PANEL
COOLING FAN MOTOR 1 (AT LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (AT RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1 (AD FAN RELAY) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 2 (FAN RELAY) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 3 (FAN RELAY 3) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 4 (FAN RELAY 2) (IN MAIN FUSE, RELAY BOX)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JC-02
LOW HI
LT GRN/BLK WIRE
MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL)
METER FUSE
MID
POWERTRAIN CONTROL MODULE (PCM) (BEHIND LEFT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> 2.3l, cooling fan circuit -> CENTER PANEL
center panel wiring diagram (2 of 3)
A/C FUSE METER FUSE
A/C RELAY (IN MAIN FUSE, RELAY BOX)
AD FAN FUSE FAN FUSE
AIR INTAKE ACTUATOR (BEHIND RIGHT SIDE OF DASH)
AIRFLOW MODE ACTUATOR (BEHIND RIGHT SIDE OF DASH)
AMBIENT TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
BLOWER RELAY (ON FUSE BLOCK)
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
BRN WIRE
BRN/YEL WIRE
CENTER PANEL
COOLING FAN MOTOR 1 (AT LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (AT RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1 (AD FAN RELAY) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 2 (FAN RELAY) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 3 (FAN RELAY 3) (IN MAIN FUSE, RELAY BOX)
COOLING FAN RELAY 4 (FAN RELAY 2) (IN MAIN FUSE, RELAY BOX)
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
EVAPORATOR TEMPERATURE SENSOR (BEHIND CENTER OF DASH)
FAN SWITCH
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
JC-02
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
MAG FUSE BLOWER FUSE
MAGNETIC CLUTCH (LEFT FRONT OF ENGINE)
MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL)
MID
MODE SWITCH
NCA WIRE
OFF
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND LEFT SIDE OF DASH)
REAR WINDOW DEFROSTER RELAY (IN MAIN FUSE, RELAY BOX)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RESISTOR
RUN WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> 2.3l, manual a/c circuit -> CENTER PANEL
center panel wiring diagram (3 of 3)
AUTOMATIC A/C
BLK WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU/YEL WIRE
CENTER PANEL
CLIMATE CONTROL UNIT
DEFOG FUSE
FILAMENT
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN
JC-03
LEFT POWER MIRROR HEATER OUTER MIRROR (AT MIRROR)
LT GRN WIRE
M DEF FUSE
MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL)
MANUAL A/C
POWER OUTSIDE MIRROR SWITCH (BEHIND RIGHT END OF DASH)
REAR WINDOW DEFROSTER RELAY (IN MAIN FUSE, RELAY BOX)
RED/BLU WIRE
RIGHT POWER MIRROR HEATER OUTER MIRROR (AT MIRROR)
RUN WIRE
S WARM FUSE
VIO/RED WIRE
YEL WIRE
Go to component -> Defoggers circuit -> CENTER PANEL
