Wiring diagram engine performance 2.3l for Mazda 6 GG (2002-2005)

A/C SYSTEM A/C SYSTEM STARTING/ CHARGING SYSTEM ANTI-THEFT SYSTEM BAROMETRIC PRESSURE SENSOR (LEFT REAR OF ENGINE COMPT) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE CAPACITOR (LEFT REAR OF ENGINE COMPT) COMPUTER DATA LINES SYSTEM ENG B + FUSE ENG BAR FUSE ENG BAR 2 FUSE INJ FUSE ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) ENGINE IG FUSE ETC RELAY FUEL PUMP FUSE ETC FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ACC AND RUN IGNITION COIL INSTRUMENT CLUSTER JB-01 JB-02 JC-02 JOINT BOX (BEHIND LEFT KICK PANEL) LT GRN/BLK WIRE MAIN FUSE, RELAY BOX (LEFT FRONT INNER FENDER PANEL) MAIN RELAY METER IG FUSE MICRO COMP- UTER MIL IND NCA WIRE ORG/ WIRE ORG/BLU WIRE PNK 1 2 3 4 5 6 WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

1 2 3 4 PNK WIRE BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE EGR VALVE (TOP REAR OF ENGINE) FUEL GAUGE SENDING UNIT FUEL PUMP FUEL PUMP UNIT (ON FUEL TANK) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES MAIN FUSE, RELAY BOX (ON LEFT FRONT INNER FENDER PANEL) STOP FUSE MASS AIRFLOW/ INTAKE AIR TEMPERATURE SENSOR (REAR OF ENGINE) OIL CONTROL VALVE (RIGHT FRONT OF ENGINE) PNK 1 2 3 4 5 6 WIRE PNK WIRE PNK/BLU WIRE PURGE SOLENOID VALVE (TOP REAR OF ENG) RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE THROTTLE ACTUATOR THROTTLE POSITION SENSOR VARIABLE INTAKE-AIR SYSTEM CONTROL SOLENOID VALVE (LEFT FRONT OF ENG) VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

1 2 3 4 PNK WIRE 2 3 4 5 PNK WIRE A/T BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE JC-01 (LEFT SIDE OF ENGINE COMPT) JC-02 (BEHIND LEFT SIDE OF DASH) M/T NCA WIRE NEUTRAL SWITCH CLUTCH SWITCH (M/T) (BEHIND LEFT SIDE OF DASH) PNK WIRE PNK/BLU WIRE POWER STEERING PRESSURE SWITCH (LEFT FRONT SIDE OF ENGINE) RED WIRE RED/BLK WIRE RED/GRN WIRE STARTING/ CHARGING SYSTEM VEHICLE SPEEDOMETER SENSOR (M/T W/O ABS) (LEFT REAR OF ENGINE) VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

2 3 4 5 PNK WIRE A/C SYSTEM BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/YEL WIRE COOLING FANS SYSTEM CRUISE CONTROL SYSTEM EVAP SYSTEM LEAK DETECTION PUMP (UNDER REAR OF VEHICLE, NEAR FUEL PUMP) FUEL INJECTORS FUEL PUMP RELAY GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE HEATED OXYGEN SENSOR (FRONT) (REAR OF ENGINE COMPT) HEATED OXYGEN SENSOR (REAR) (REAR OF ENGINE COMPT) JB-02 JB-05 JOINT BOX (BEHIND LEFT KICK PANEL) ORG/ WIRE PNK WIRE PNK/BLU WIRE POWERTRAIN CONTROL MODULE (BEHIND LEFT SIDE OF DASH) RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE STARTING/ CHARGING SYSTEM VIO/RED WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
