Mazda 6 GG (2002-2005) neutral switch Wiring diagram
This page shows the only wiring diagram for the component.neutral switch, which is found in the car Mazda 6 GG (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram neutral switch (1 of 1)
10 11 PNK WIRE
23 24 PNK WIRE
24 25 26 PNK WIRE
9 10 11 12 PNK WIRE
A/T
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH SWITCH (M/T) (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
J/C X-23
JC-01 (LEFT SIDE OF ENGINE COMPT)
JC-02 (BEHIND LEFT SIDE OF DASH)
LEFT OIL CONTROL VALVE (FRONT OF LEFT CYL BANK)
LT GRN/RED WIRE
M/T
NCA WIRE
NEUTRAL SWITCH
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT OIL CONTROL VALVE (FRONT OF RIGHT CYL BANK)
STARTING/ CHARGING SYSTEM
VEHICLE SPEEDOMETER SENSOR (M/T W/O ABS) (REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l (3 of 4) -> NEUTRAL SWITCH
