Mazda 6 GG (2002-2005) headlight switch off tns Wiring diagrams

AUTO LIGHT-OFF CONTROL MODULE (BEHIND LEFT SIDE OF DASH) BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM FLASH TO PASS SWITCH LOW HIGH FOG FUSE FRONT FOG LIGHT RELAY FRONT FOG LIGHT SWITCH FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEAD HEAD HL FUSE HEAD HR FUSE HEAD LL FUSE HEAD LR FUSE HEADLIGHT RELAY HEADLIGHT SWITCH HEADLIGHT SWITCH OFF TNS HIGH BEAM HIGH BEAM IND HOT AT ALL TIMES HOT IN ACC AND RUN INSTRUMENT CLUSTER JB-01 JC-01 (LEFT SIDE OF ENGINE COMPARTMENT) JOINT BOX (BEHIND LEFT KICK PANEL) LEFT FRONT FOG LIGHT LEFT HEADLIGHT LOW BEAM LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE, RELAY BOX (ON LEFT FRONT INNER FENDER) METER METER IG FUSE PARKING BRAKE SWITCH POWER WINDOWS SYSTEM RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FOG LIGHT RIGHT HEADLIGHT ROOM FUSE TNS WHT WIRE YEL WIRE YEL/GRN WIRE

AUTO LIGHT-OFF CONTROL MODULE (BEHIND LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN/RED WIRE C-01 C-01 INSTRUMENT CLUSTER EXTERIOR LIGHT SYSTEM INTERIOR LIGHTS SYSTEM FLASH TO PASS SWITCH LOW HIGH FOG FUSE FRONT FOG LIGHT RELAY FRONT FOG LIGHT SWITCH FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE HEAD HEAD HL FUSE HEAD HR FUSE HEAD LL FUSE HEAD LR FUSE HEADLIGHT RELAY HEADLIGHT SWITCH HEADLIGHT SWITCH OFF TNS HIGH BEAM HOT AT ALL TIMES HOT IN ACC AND RUN JB-01 JC-01 (LEFT SIDE OF ENGINE COMPARTMENT) JOINT BOX (BEHIND LEFT KICK PANEL) LEFT FRONT FOG LIGHT LEFT HEADLIGHT LOW BEAM LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE, RELAY BOX (ON LEFT FRONT INNER FENDER) METER METER IG FUSE POWER WINDOWS SYSTEM RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FOG LIGHT RIGHT HEADLIGHT ROOM FUSE TNS WHT WIRE YEL WIRE
