Mazda 6 GG (2002-2005) air conditioning, power tops, mirrors Wiring diagram
This page shows the only wiring diagram for the component.air conditioning, power tops, mirrors, which is found in the car Mazda 6 GG (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioning, power tops, mirrors (1 of 1)
A/C FUSE
ACCES- SORY SOCKET
AIR CONDITIONING
AIR CONDITIONING COOLING FANS COOLING FANS
AIR CONDITIONING, POWER TOPS, MIRRORS
AUDIO FUSE PWR SEAT FUSE ABS FUSE
BACK FUSE
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BRN WIRE
BTN FUSE
CIGAR FUSE MIRROR FUSE D LOCK FUSE R CIGAR FUSE
DEFOG FUSE
DOOR LOCKS
ENGINE CONTROLS
ENGINE CONTROLS POWER WINDOWS
ENGINE CONTROLS TRANSMISSION CONTROLS
ENGINE IG FUSE
ENGINE, ANTI-THEFT
EXT LIGHTS
EXT LIGHTS (M/T), TRANSMISSION (2.3L W/AT)
EXT LIGHTS, INT LIGHTS
FAN FAN 1 FUSE AD FAN FAN 2 FUSE (2.3L) (2.3L) MAG FUSE
FOG FUSE
FROM IG KEY FUSE (DIAGRAM 1 OF 1)
FUEL PUMP FUSE FUSE
FUSE
GRN WIRE
HEADLIGHTS CIGAR LIGHTER DOOR LOCKS SYSTEM
HEADLIGHTS SYSTEM
HORNS, EXT LIGHTS
IGNITION SWITCH
JB-01 JB-03
JB-01 JB-03 JB-01 JB-03
JB-01 JOINT BOX (BEHIND LEFT KICK PANEL)
JB-02
JB-02 JB-01
JB-03
MAIN FUSE
MAIN FUSE BLOCK (LEFT FRONT INNER FENDER PANEL)
METER IG FUSE WIPER FUSE
OFF
OPENER FUSE
ORG/ WIRE
PNK WIRE
POWER MIRROR, AUDIO SYSTEM
RED WIRE
ROOM FUSE
RUN WIRE
SAS FUSE METER ACC FUSE
SEAT FUSE
SEATS SOUND SYSTEMS ANTI-LOCK BRAKES DEFOGGER
SEATS, DEFOGGER
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM EXTERIOR LIGHTS
STOP FUSE HAZ FUSE
SUPPLEMENTAL RESTRAINTS, ANTI-LOCK BRAKES
TCM FUSE PWR WINDOW FUSE
TO BLOWER FUSE (DIAGRAM 1 OF 1)
WHT WIRE
WIPER/WASHER WIPER/WASHER
YEL WIRE
Go to component -> Power distribution circuit -> AIR CONDITIONING, POWER TOPS, MIRRORS
