Mazda 5 I facelift (2007-2010) preset preset vol + vol - Wiring diagrams
This page contains all the electrical diagrams for the component. preset preset vol + vol -, in which he is found in the car Mazda 5 I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
preset preset vol + vol - wiring diagram (1 of 2)
0922-202 CLOCK SPRING (IN STEERING COLUMN)
0922-203
A/T
AUDIO CONTROL SWITCH
BACKUP LIGHT SWITCH (ON TRANSAXLE
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HANDS-FREE TELEPHONE UNIT
INSTRUMENT CLUSTER SYSTEM
JOINT
M/T
MICROPHONE (BEHIND RIGHT CENTER OF DASH)
MODE MUTE
NCA WIRE
ORG/ WIRE
POSITION
PRESET PRESET VOL + VOL -
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
TRANSAXLE RANGE SWITCH
TRANSMISSIONS SYSTEM
VIO WIRE
W/ HANDSFREE TELEPHONE UNIT W/O HANDSFREE TELEPHONE UNIT
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (2 of 2) -> PRESET PRESET VOL + VOL -
