Mazda 5 I facelift (2007-2010) check engine ind Wiring diagrams
This page contains all the electrical diagrams for the component. check engine ind, in which he is found in the car Mazda 5 I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram check engine ind (1 of 2)
1-5
A/T IND
AIR BAG IND
ANTI-THEFT SYSTEM
BCM (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SENSOR (IN BRAKE FLUID RESERVOIR)
BRAKE IND
BRAKE SWITCH 2 (AT TOP OF BRAKE PEDAL ASSEMBLY)
BRN/WHT WIRE
BRN/YEL WIRE
BUZZER
CAR-NAVIGATION UNIT (BEHIND RIGHT SIDE OF DASH)
CHARGE IND
CHECK ENGINE IND
COMPUTER DATA LINES SYSTEM WIPER/WASHER SYSTEM
CRUISE (AMBER) IND
CRUISE (GREEN) IND
DOOR IND
DOOR LOCKS SYSTEM WARNING SYSTEMS
DRIVE CIRCUIT SELECTOR INDICATOR
EPS IND
FUEL GAUGE
FUEL GAUGE SENDER UNIT (ON FUEL TANK)
FUEL LOW IND
FUSE BLOCK (BEHIND RIGHT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM IND
INSTRUMENT CLUSTER
J/C C-11 (BEHIND RIGHT END OF DASH)
J/C C-12 (BEHIND CENTER OF DASH)
J/C C-31 (BEHIND LEFT END OF DASH)
JC G-02
L TURN IND
LEFT FRONT DOOR LATCH SWITCH (IN DRIVER'S DOOR)
LT GRN/RED WIRE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER FUSE
MICROCOMPUTER
NAVIGATION SYSTEM
ODOMETER/ TRIPMETER
OIL IND
PANEL LIGHT CONTROL
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK/BLK WIRE
R TURN IND
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT DOOR LATCH SWITCH (IN FRONT PASSENGER'S DOOR)
ROOM FUSE
SEAT BELTS IND
SECURITY IND
SPEEDOMETER
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TNS IND
TPMS CONTROL UNIT
TPMS IND
TRIPMETER SWITCH
VIO WIRE
VIO/GRN WIRE
WASHER IND
WATER TEMPERATURE GAUGE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Instrument cluster circuit -> CHECK ENGINE IND
Wiring diagram check engine ind (2 of 2)
ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CHECK ENGINE IND
COMPUTER DATA LINES SYSTEM
DRIVE-BY-WIRE-RELAY (ETC RELAY)
ENG +B FUSE
ENG BA FUSE
ENG BAR 2 FUSE
ENG BAR FUSE
ETC FUSE
EVAP SYSTEM LEAK DETECTION PUMP (UNDER REAR OF VEHICLE)
FUEL FUSE
GRN WIRE
GRN/BLK WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JOINT CONNECTOR C-34 (LEFT SIDE OF ENGINE COMPARTMENT)
LT GRN WIRE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
MAIN RELAY (EGI MAIN RELAY)
MASS AIR FLOW/ INTAKE AIR TEMPERATURE SENSOR (REAR OF ENGINE)
MICRO COMPUTER
ORG/ WIRE
PNK WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 2.3l (2 of 4) -> CHECK ENGINE IND
