Mazda 5 I (2005-2007) w/ side, curtain airbag system) Wiring diagram
This page shows the only wiring diagram for the component.w/ side, curtain airbag system), which is found in the car Mazda 5 I (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ side, curtain airbag system) (1 of 1)
AIR BAG
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLOCK- SPRING
DRIVER SIDE AIR BAG MODULE
DRIVER-SIDE CURTAIN AIRBAG MODULE (LEFT "D" PILLAR)
DRIVER-SIDE SIDE AIR BAG MODULE
DRIVER-SIDE SIDE AIR BAG SENSOR 1 (BASE OF LEFT "B" PILLAR)
DRIVER-SIDE SIDE AIR BAG SENSOR 2 (BASE OF LEFT "C" PILLAR)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
INFLATOR
INFLATOR 1
INFLATOR 2
INSTRUMENT CLUSTER
MICROCOMPUTER
NCA WIRE
ORG/ WIRE
PASSENGER SIDE AIR BAG MODULE
PASSENGER-SIDE CURTAIN AIRBAG MODULE (RIGHT "D" PILLAR)
PASSENGER-SIDE SIDE AIR BAG MODULE
PASSENGER-SIDE SIDE AIR BAG SENSOR 1 (BASE OF RIGHT "B" PILLAR)
PASSENGER-SIDE SIDE AIR BAG SENSOR 2 (BASE OF RIGHT "C" PILLAR)
RED WIRE
SEAT BELTS
SHORT BAR
W/ SIDE, CURTAIN AIRBAG SYSTEM)
W/ SIDE, CURTAIN AIRBAGS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> W/ SIDE, CURTAIN AIRBAG SYSTEM)
