Mazda 5 I (2005-2007) front corner of engine compartment, in washer fluid reservoir) wiring diagram
This page shows the only wiring diagram for the component.front corner of engine compartment, in washer fluid reservoir), which is found in the car Mazda 5 I (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front corner of engine compartment, in washer fluid reservoir) wiring diagram (1 of 1)
AUTOSTOP SWITCH
BCM (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CIRCUIT BREAKER
FRONT CORNER OF ENGINE COMPARTMENT, IN WASHER FLUID RESERVOIR)
FRONT WIPER FUSE
FUSE BLOCK (BEHIND RIGHT END OF DASH) METER FUSE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HI LO
HOT IN ON
HOT IN ON OR START
INSTRUMENT CLUSTER (W/ WASHER FLUID-LEVEL WARNING LIGHT)
INT (AUTO)
MIST
OFF
PNK WIRE
RAIN SENSOR (W/ AUTO WIPER) (TOP CENTER OF WINDSHIELD)
RED WIRE
RED/GRN WIRE
VIO WIRE
VIO/GRN WIRE
WARNING SYSTEM
WASHER FLUID LEVEL SENSOR (RIGHT
WASHER IND
WASHER SWITCH
WHT WIRE
WINDSHEILD WIPER HIGH RELAY
WINDSHEILD WIPER RELAY
WINDSHIELD WIPER MOTOR (CENTER REAR OF ENGINE COMPT)
WINDSHIELD WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> FRONT CORNER OF ENGINE COMPARTMENT, IN WASHER FLUID RESERVOIR)
