Mazda 5 I (2005-2007) closer left fuse wiring diagram
This page shows the only wiring diagram for the component.closer left fuse, which is found in the car Mazda 5 I (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
closer left fuse wiring diagram (1 of 1)
BLK WIRE
BLU/WHT WIRE
CLOSER LEFT FUSE
CLOSER RIGHT FUSE
HOT AT ALL TIMES
LEFT EASY CLOSURE MOTOR
LEFT EASY CLOSURE SWITCH
LEFT SLIDE DOOR LOCK
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
ORG/ WIRE
RED/GRN WIRE
RIGHT EASY CLOSURE MOTOR
RIGHT EASY CLOSURE SWITCH
RIGHT SLIDE DOOR LOCK
VIO WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Power sliding door circuit -> CLOSER LEFT FUSE
