Mazda 5 I (2005-2007) clock spring (in steering column) wiring diagram
This page shows the only wiring diagram for the component.clock spring (in steering column), which is found in the car Mazda 5 I (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
clock spring (in steering column) wiring diagram (1 of 1)
2 0922-203 2 0922-202
AUDIO CONTROL SWITCH (W/O CRUISE CONTROL)
AUDIO UNIT
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
BRN WIRE
BRN/BLK WIRE
CAR-NAVIGATION UNIT (BEHIND RIGHT SIDE OF DASH)
CLIMATE CONTROL UNIT
CLOCK SPRING (IN STEERING COLUMN)
CRUISE CONTROL SWITCH (W/ CRUISE CONTROL)
GLOVE COMPARTMENT LIGHT
HAZARD WARNING SWITCH
HOT AT ALL TIMES
IGNITION KEY ILLUMINATION
ILL
ILLU FUSE
INFORMATION DISPLAY
INSTRUMENT CLUSTER
LCD UNIT (W/ CAR NAVIGATION SYSTEM)
LT GRN WIRE
LT GRN/RED WIRE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
MANUAL A/C AUTOMATIC A/C
MICROCOMPUTER
NCA WIRE
RED WIRE
ROOM FUSE
SELECTOR LEVER (IN CENTER CONSOLE)
TNS RELAY
Go to component -> Instrument illumination circuit -> CLOCK SPRING (IN STEERING COLUMN)
