Radio circuit, w/o bose for Mazda 3 BP (2019-2024)

0920-134 0920-135 BLK WIRE BLU WIRE BRN WIRE C-14 CAN L CENTER DISPLAY COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT DATA P GMSL IN CAMERA GMSL OUT DISP GNSS GPS ANTENNA GRN WIRE GRY WIRE IN N IN P J/C C-41 (LEFT SIDE OF DASH) J/C C-42 (LEFT CENTER OF DASH) LT BLU WIRE LT GRN WIRE MOST IN N MOST IN P NCA WIRE OUT OUT N OUT P PARKING ASSIST UNIT (OPTICAL)/ 360 DEGREE VIEW MONITOR CONTROL MODULE PNK WIRE PPL/VIO WIRE PWR PWR CTRL OUT +B REAR MOUNT CAMERA RED WIRE UART USB PORT USB PORT/SD CARD SLOT HUB V BUS DATA N VIO WIRE W/ PARKING ASSIST UNIT W/ TELEMATICS COMMUNICATION SYSTEM W/O PARKING ASSIST UNIT W/O TELEMATICS COMMUNICATION SYSTEM WHT WIRE YEL WIRE

0914-602 0914-603 0914-604 0922-201 0922-205 BLK WIRE BLU WIRE BRN WIRE C-16 C-17 CAN L CLOCKSPRING COMPUTER DATA LINES SYSTEM DATA N DATA P EARLY PRODUCTION GNSS SIG GRN WIRE GRY WIRE HUNG INFO J/C C-45 LATE PRODUCTION LT BLU WIRE LT GRN WIRE MICROPHONE MUTE NCA WIRE PICK PNK WIRE PPL/BLK WIRE PPL/VIO WIRE RED WIRE SEEK SOURCE STEERING SWITCH UP (+) VBUS VIO WIRE VOICE VOL (-) WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE C-03 C-04 C-05 C-13 C-14 C-23 COMPUTER DATA LINES SYSTEM CRUISE IN FUSE 13 FUSE 22 FUSE 46 FUSE 48 FUSE 51 FUSE BLOCK GRY WIRE HOT AT ALL TIMES INFO INSTRUMENT CLUSTER J/C C-39 J/C C-41 LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT PNK WIRE PPL/LT GRN WIRE RED WIRE RELAY & FUSE BLOCK RELAY 2 ENERGIZED SAS CONTROL MODULE STRG SW TEL ANTENNA 2 (SUB) VIO WIRE WARNING/INDICATOR LIGHTS WHT WIRE YEL WIRE

0920-114 AM/FM ANT CONT ANTENNA AMPLIFIER (CENTER REAR OF ROOF) BLK WIRE BLU WIRE BRN WIRE C-14 C-22 C-23 C-24 C-25 CAN L COMPUTER DATA LINES SYSTEM FL DOOR N FL DOOR P FL TWEETER N FL TWEETER P FL WOOFER N FL WOOFER P FM ANTENNA AMPLIFIER FR DOOR N FR DOOR P FR TWEETER N FR TWEETER P FR WOOFER N FR WOOFER P GRN WIRE GRY WIRE HATCHBACK IN N IN P LEFT COWL SIDE WOOFER LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NCA WIRE OUT OUT N OUT P PNK WIRE RED WIRE REMOTE TUNER (RT) RIGHT COWL SIDE WOOFER RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER RL DOOR N RL DOOR P RR DOOR N RR DOOR P SEDAN TAN WIRE VIO WIRE WHT WIRE YEL WIRE
