Car Wiring Diagrams for Instrument illumination circuit for Mazda 3 BP (2019-2024)

+B AF 0922-201 0922-205 AM CAN-L 1 AK CAN-H 1 AA COMBI GND AUTO OFF B+ (ILL +) BLK WIRE BLU WIRE BRN WIRE BUZZER C-03 C-04 C-07 C-09 C-13 C-14 C-22 C-23 C-24 C-25 C-47 C-46 CAN L CLUSTER SWITCH 1 CLUSTER SWITCH 2 COMBI LIGHT TNS COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH CRUISE CONTROL SWITCH/ CLOCKSPRING/STEERING SWITCH DRIVER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT ELECTRIC PARKING BRAKE SWITCH FLASH-TO-PASS HEAD TNS FUSE 16 FUSE 22 FUSE 49 FUSE BLOCK GND SIG AJ GRY WIRE HOT AT ALL TIMES HOT W/ IG DCDC AN ILL ILL 1 ILL 4 ILL 5 ILL GND PNK ILL 5 WIRE ILL LIGHT ILL PLUS ILL+ GND INSTRUMENT CLUSTER J/C C-39 J/C C-45 (LEFT SIDE OF DASH) LEFT "C" PILLAR) LEFT DOOR LOCK SWITCH LEFT REAR POWER WINDOW SUBSWITCH LIGHT HEAD LIGHT HI LIGHT OFF LIGHT PASS LIGHT SWITCH/TURN SWITCH/ HIGH BEAM CONTROL SWITCH LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT PNK WIRE POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH PPL/GRN WIRE PPL/LT GRN WIRE PPL/VIO WIRE PPL/YEL WIRE PW ILL 1 PW RR SW GND RED WIRE RELAY & FUSE BLOCK RIGHT DOOR LOCK SWITCH RIGHT FRONT POWER WINDOW SUB SWITCH RIGHT REAR POWER WINDOW SUB SWITCH SW GND VIO WIRE WARNING/INDICATOR LIGHTS WHT WIRE YEL WIRE
