Mazda 3 BP (2019-2024) sedan hatchback Wiring diagrams
This page contains all the electrical diagrams for the component. sedan hatchback, in which he is found in the car Mazda 3 BP (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sedan hatchback wiring diagram (1 of 2)
0518-102
BRN WIRE
C-02
C-13
C-16
C-22
C-27
C-46
C-47
C-59
C-69
CAN L
CAN-H
DASH-ELECTRICAL SUPPLY UNIT (RIGHT SIDE OF DASH)
DRIVER MONITORING CAMERA UNIT
ELECTRICAL SUPPLY UNIT
FORWARD SENSING CAMERA (FSC)
GRY WIRE
HS CAN-H
HS CAN-L
J/C C-39
JOINT BOX 1 (LEFT SIDE OF DASH)
LT BLU WIRE
NCA WIRE
PARKING ASSIST UNIT (OPTICAL)/ 360 DEGREE VIEW MONITOR CONTROL MODULE
PNK WIRE
RED WIRE
SEDAN HATCHBACK
SHIFT PANEL (INDICATOR)
TELEMATICS COMMUNICATION UNIT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (3 of 5) -> SEDAN HATCHBACK
sedan hatchback wiring diagram (2 of 2)
0613-102
A/C RELAY
ACCESSORY SOCKET
AFS CONTROL MODULE/ AUTO LEVELING CONTROL MODULE
BCM
BLK WIRE
BLK/WHT WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
C-03
C-09
C-10
C-59
C-60
C-66
C-67
C-69
C-70
ELECTRIC VARIABLE VALVE TIMING RELAY
EPS CONTROL UNIT
FROM BCM (DIAGRAM 3 OF 5)
FROM FUSE 28 (DIAGRAM 1 OF 5)
FRONT RADAR SENSOR
FUEL PUMP RELAY
FUSE 11
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 24
FUSE 25
FUSE 29
FUSE 3
FUSE 30
FUSE 31
FUSE 37
FUSE 4
FUSE 40
FUSE 5
FUSE 53
FUSE 54
FUSE 7
GRN WIRE
HATCHBACK
HORN RELAY
J/C C-28
J/C C-58
J/C C-68
JOINT BOX 3
LEFT FRONT SIDE RADAR SENSOR
LEFT REAR SIDE RADAR SENSOR
LT BLU WIRE
LT GRN WIRE
MAIN RELAY
NCA WIRE
PARKING ASSIST UNIT (ULTRASONIC)
PCM
PNK WIRE
PPL
PPL/LT GRN WIRE
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY & FUSE BLOCK
RIGHT FRONT SIDE RADAR SENSOR
RIGHT REAR SIDE RADAR SENSOR
SEDAN
SEDAN HATCHBACK
SUB RELAY
TAN WIRE
VIO WIRE
W/ BLIND SPOT MONITORING (BSM) SYSTEM
W/ PARKING SENSOR SYSTEM
W/O BLIND SPOT MONITORING (BSM) SYSTEM
W/O PARKING SENSOR SYSTEM
WHT WIRE
WINDSHIELD WIPER DE-ICER RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> SEDAN HATCHBACK
