Mazda 3 BP (2019-2024) electrical controlled brake unit Wiring diagram
This page shows the only wiring diagram for the component.electrical controlled brake unit, which is found in the car Mazda 3 BP (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electrical controlled brake unit (1 of 1)
0518-102
0914-602
AFS CONTROL MODULE/ AUTO LEVELING CONTROL MODULE
BACKUP POWER SUPPLY
BCM
C-04
C-13
C-21
C-46
C-47
C-61
C-62
DSC HU/CM
EARLY PRODUCTION
ELECTRICAL CONTROLLED BRAKE UNIT
ELECTRICAL SUPPLY UNIT
EPS CONTROL MODULE
FROM FUSE 22 (DIAGRAM 3 OF 5)
FROM J/C C-30 (DIAGRAM 3 OF 5)
FUSE 48
FUSE 49
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER
J/C C-41
JOINT BOX 1
LATE PRODUCTION
MAZDA M HYBRID BATTERY
NCA WIRE
PNK C-09 WIRE
POSITION MEMORY CONTROL MODULE/ SEAT WARMER CONTROL UNIT
PPL/GRN WIRE
PPL/GRY WIRE
PPL/TAN WIRE
RELAY & FUSE BLOCK
SAS CONTROL MODULE
SEAT WARMER CONTROL UNIT
SEAT WEIGHT SENSOR CONTROL MODULE
SELECTOR LEVER COMPONENT
SHIFT PANEL (INDICATOR)
TAN WIRE
TELEMATICS COMMUNICATION UNIT
W/ MEMORY
W/O MEMORY
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> ELECTRICAL CONTROLLED BRAKE UNIT
