Car Wiring Diagrams for Headlamps leveling circuit for Mazda 3 BM facelift (2016-2019)

AFS CONTROL MODULE AFS OFF SWITCH (IF EQUIPPED) AUTO LEVELING SENSOR BLK WIRE BLU WIRE BRN WIRE BSM OFF SWITCH (IF EQUIPPED) C-05 C-24 C-51 C-52 C-52 C-54 CLUSTER SWITCH COMPUTER DATA LINES SYSTEM DSC OFF SWITCH GRN WIRE GRY WIRE HOT W/ INSTRUMENT CLUSTER JOINT BOX 1 (LEFT KICK PANEL) LDWS SWITCH LEFT HEADLIGHT LEVELING ACTUATOR/LEFT SWIVEL ACTUATOR LT GRN WIRE METER 1 FUSE MICROCOMPUTER NCA WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK RIGHT HEADLIGHT LEVELING ACTUATOR/RIGHT SWIVEL ACTUATOR SRS 1 FUSE TAN WIRE TPMS SET SWITCH (IF EQUIPPED) VIO WIRE WARNING/ INDICATOR LAMPS WHT WIRE YEL WIRE
