Mazda 3 BM facelift (2016-2019) w/ single light type Wiring diagram
This page shows the only wiring diagram for the component.w/ single light type, which is found in the car Mazda 3 BM facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ single light type (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-08
C-18
C-20
C-21
C-22
C-23
CARGO COMPARTMENT LIGHT (HATCHBACK)
CONDENSER
DOOR
FRONT MAP LIGHT
GRN WIRE
GRY WIRE
GRY/RED WIRE
HATCHBACK
HOT AT ALL TIMES
J/C C-40
LEFT "C" PILLAR)
LEFT FRONT DOOR LATCH, LOCK ACTUATOR
LEFT REAR DOOR LATCH, LOCK ACTUATOR
LEFT VANITY MIRROR ILLUMINATION (IF EQUIPPED)
OFF
ORG/ WIRE
RBCM
REAR MAP LIGHT
RED WIRE
RELAY & FUSE BLOCK
RIGHT END OF DASH)
RIGHT FRONT DOOR LATCH, LOCK ACTUATOR
RIGHT REAR DOOR LATCH, LOCK ACTUATOR
RIGHT VANITY MIRROR ILLUMINATION (IF EQUIPPED)
ROOM FUSE
SEDAN
TAN WIRE
TRUNK COMPARTMENT LIGHT
W/ DUAL LIGHT TYPE
W/ SINGLE LIGHT TYPE
W/O REAR MAP LIGHT W/ REAR MAP LIGHT
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> W/ SINGLE LIGHT TYPE
