Mazda 3 BM facelift (2016-2019) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Mazda 3 BM facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (1 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (1 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

5-PIN TYPE 10-PIN TYPE AUTO DIMMING MIRROR BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BRN WIRE C-03 C-04 C-08 C-12 C-52 C-55 COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES J/B NO. 1 J/B NO. 2 (LEFT SIDE OF DASH) J/C 10 J/C C-35 METER 1 FUSE RBCM RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED ROOM FUSE VIO WIRE YEL WIRE

Go to component -> Auto dimming mirror circuit -> RED WIRE

Wiring diagram red (2 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (2 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

BLK WIRE BRN WIRE C-04 C-09 C-12 C-19 C-33 C-34 C-52 C-54 C-59 CAN L CAN-H CLIMATE CONTROL UNIT CONNECTIVITY MASTER UNIT DATA LINK CONNECTOR (DLC) 2 DUAL ENG +B FUSE EPS CONTROL MODULE HOT AT ALL TIMES HS CAN-H HS CAN-L JOINT BOX 1 JOINT BOX 2 LEFT BSM CONTROL MODULE LT BLU WIRE MS CAN-H MS CAN-L RBCM RED WIRE RELAY & FUSE BLOCK RIGHT BSM CONTROL MODULE SAS CONTROL MODULE SINGLE START STOP UNIT VIO WIRE W/ BOSE, CENTER DISPLAY W/O BOSE, W/ CENTER DISPLAY WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit (1 of 3) -> RED WIRE

Wiring diagram red (3 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (3 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

A/T AFS CONTROL MODULE AUDIO AMPLIFIER BRN WIRE C-01 C-03 C-05 C-09 C-12 C-51 C-54 DC-DC CONVERTER ELECTRIC PARKING BRAKE CONTROL MODULE FBCM FORWARD SENSING CAMERA (FSC) GRY WIRE HS CAN-H HS CAN-L INSTRUMENT CLUSTER J/C C-32 J/C C-40 JOINT BOX 1 M/T MS CAN-H MS CAN-L OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE RED WIRE TCM W/ BOSE, RADAR CRUISE CONTROL W/O BOSE, RADAR CRUISE CONTROL WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit (2 of 3) -> RED WIRE

Wiring diagram red (4 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (4 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

A/T AUDIO UNIT BLUETOOTH UNIT (W/O CENTER DISPLAY) (RIGHT KICK PANEL) BRN WIRE CD PLAYER CHECK CONNECTOR DSC HU/CM GRY WIRE HS CAN-H HS CAN-L J/C C-36 J/C C-60 PCM RADAR UNIT RED WIRE RESISTOR TUNER, AMP UNIT W/ BOSE, CENTER DISPLAY W/ CD PLAYER W/O BOSE, W/ CENTER DISPLAY W/O CD PLAYER WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit (3 of 3) -> RED WIRE

Wiring diagram red (5 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (5 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

AA C-21 BLK WIRE BLU WIRE BRN WIRE C-03 C-05 C-17 C-20 C-21 CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM CONDENSER DEFOG FUSE FBCM FUSE BLOCK GRN WIRE HATCHBACK HEATER HOT AT ALL TIMES LEFT "C" PILLAR) LEFT HEATED OUTER MIRROR M DEF FUSE MANUAL A/C SINGLE AUTOMATIC A/C DUAL AUTOMATIC A/C NCA WIRE REAR WINDOW DEFROSTER REAR WINDOW DEFROSTER RELAY RED WIRE RELAY & FUSE BLOCK RIGHT END OF DASH) RIGHT HEATED OUTER MIRROR SEDAN VIO WIRE WHT WIRE YEL WIRE

Go to component -> Defoggers circuit -> RED WIRE

Wiring diagram red (6 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (6 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

0613-102 BLK WIRE BLU WIRE C-52 C-54 COMPUTER DATA LINES SYSTEM EPS CONTROL MODULE EPS FUSE HOT AT ALL TIMES MAIN FUSE INSTRUMENT CLUSTER JOINT BOX 1 METER 1 FUSE MICRO COMPUTER RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED SOUND SYSTEMS SRS 1 FUSE TAN WIRE VIO WIRE WARNING/ IND LIGHTS WHT WIRE

Go to component -> Electronic power steering circuit -> RED WIRE

Wiring diagram red (7 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (7 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

ACTIVE DRIVING DISPLAY BLK WIRE BLU WIRE BRN WIRE BUZZER C-04 C-09 C-26 C-33 C-34 C-51 C-52 C-53 C-54 CLOCK- SPRING COMPUTER DATA LINES SYSTEM DIMMER CANCEL SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES HS CAN_H HS CAN_L ILLUMINATION INDICATOR UNIT INSTRUMENT CLUSTER JOINT BOX 1 JOINT BOX 2 LCD LCD (X 2) LCD (X 3) LT BLU WIRE LT GRN WIRE METER 1 FUSE MICRO COMPUTER MS CAN_H MS CAN_L NCA WIRE PANEL LIGHT CONTROL PNK WIRE RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED ROOM FUSE SEAT WARMER CONTROL UNIT SHIFT INTERLOCK SYSTEM SPEEDOMETER STEERING WARMER CONTROL UNIT TACHOMETER TAN WIRE TRANSMISSIONS SYSTEM TRIPMETER SWITCH VIO WIRE W/ ANALOG TACHOMETER W/ DIGITAL TACHOMETER W/O TACHOMETER WARNING/ INDICATOR LIGHTS WHT WIRE YEL WIRE

Go to component -> Instrument cluster circuit (1 of 2) -> RED WIRE

Wiring diagram red (8 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (8 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

BLK WIRE BRAKE FLUID LEVEL SENSOR BRN WIRE BSM OFF SWITCH C-20 C-21 C-22 C-23 CLUSTER SWITCH COMPUTER DATA LINES SYSTEM DOOR DOOR OPEN DSC OFF SWITCH DSC/TCS OFF SWITCH FBCM FUEL GAUGE SENDER UNIT GRN WIRE GRY WIRE GRY/RED WIRE HS CAN-H HS CAN-L LDWS OFF SWITCH LEFT FRONT DOOR LATCH, LOCK ACTUATOR LEFT REAR DOOR LATCH, LOCK ACTUATOR LT BLU WIRE OIL PRESS SW OIL PRESSURE SWITCH ORG/ WIRE PARKING BRAKE SWITCH POWERTRAIN CONTROL MODULE (PCM) RBCM RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR LATCH, LOCK ACTUATOR RIGHT REAR DOOR LATCH, LOCK ACTUATOR TAN WIRE TPMS SET SWITCH VIO WIRE WASHER FLUID LEVEL SENSOR WHT WIRE YEL WIRE

Go to component -> Instrument cluster circuit (2 of 2) -> RED WIRE

Wiring diagram red (9 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (9 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE C-20 C-21 C-21 AB DEFOGGER SYSTEM DOWN DOWN UP FUSE BLOCK GRN WIRE GRY WIRE HEATED OUTER MIRROR HOT W/ ACC RELAY ENERGIZED JC-16 LEFT LEFT BSM INDICATOR LIGHT LEFT RIGHT LEFT SIDE TURN LIGHT LEFT POWER OUTER MIRROR LT GRN WIRE MIRROR FUSE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK WIRE POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH RED WIRE RIGHT RIGHT BSM INDICATOR LIGHT RIGHT END OF DASH) RIGHT LEFT RIGHT POWER OUTER MIRROR RIGHT SIDE TURN LIGHT TAN WIRE UP DOWN WHT WIRE YEL WIRE

Go to component -> Power mirror circuit -> RED WIRE

Wiring diagram red (10 of 89)

Wiring diagram red for Mazda 3 BM facelift (2016-2019) (10 of 89)

Get lifetime access to Mazda 3 BM facelift (2016-2019)

AI AL AO C-20 AUTO BLK WIRE BLU WIRE C-05 C-20 C-21 C-22 C-23 CLOSE CLOSE OPEN CLOSE RELAY FUSE BLOCK GRN WIRE GRY WIRE HALL EFFECT HOT AT ALL TIMES J/C C-38 JC-16 LEFT FRONT POWER WINDOW MOTOR (IN LEFT FRONT DOOR) LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SUB SWITCH LT BLU WIRE LT GRN WIRE OPEN CLOSE OPEN RELAY P WINDOW 1 FUSE P WINDOW 2 FUSE P/W CM PNK WIRE POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH POWER-CUT SWITCH RBCM RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED RIGHT END OF DASH) RIGHT FRONT POWER WINDOW MOTOR RIGHT FRONT POWER WINDOW SUB SWITCH RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SUB SWITCH SWITCH 1 SWITCH 2 VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power windows circuit -> RED WIRE
