Mazda 3 BM facelift (2016-2019) left bsm indicator light Wiring diagrams
This page contains all the electrical diagrams for the component. left bsm indicator light, in which he is found in the car Mazda 3 BM facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left bsm indicator light (1 of 2)
AFS OFF SWITCH (IF EQUIPPED)
BLK WIRE
BLU WIRE
BRN WIRE
BSM OFF IND
BSM OFF SWITCH (IF EQUIPPED)
C-05
C-19
C-20
C-21
C-52
C-54
CLUSTER SWITCH
COMPUTER DATA LINES SYSTEM
DSC OFF SWITCH
INSTRUMENT CLUSTER
JOINT BOX 1
LDWS SWITCH
LEFT BSM CONTROL MODULE
LEFT BSM INDICATOR LIGHT
LEFT POWER OUTER MIRROR
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
METER 1 FUSE
MICROCOMPUTER
NCA WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
RIGHT BSM CONTROL MODULE
RIGHT BSM INDICATOR LIGHT
RIGHT END OF DASH)
RIGHT POWER OUTER MIRROR
TPMS SET SWITCH (IF EQUIPPED)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> LEFT BSM INDICATOR LIGHT
Wiring diagram left bsm indicator light (2 of 2)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
C-20
C-21
C-21 AB
DEFOGGER SYSTEM
DOWN
DOWN UP
FUSE BLOCK
GRN WIRE
GRY WIRE
HEATED OUTER MIRROR
HOT W/ ACC RELAY ENERGIZED
JC-16
LEFT
LEFT BSM INDICATOR LIGHT
LEFT RIGHT
LEFT SIDE TURN LIGHT LEFT POWER OUTER MIRROR
LT GRN WIRE
MIRROR FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH
RED WIRE
RIGHT
RIGHT BSM INDICATOR LIGHT
RIGHT END OF DASH)
RIGHT LEFT
RIGHT POWER OUTER MIRROR
RIGHT SIDE TURN LIGHT
TAN WIRE
UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> LEFT BSM INDICATOR LIGHT
