Blind spot monitoring circuit for Mazda 3 BM (2013-2016)

AFS OFF SWITCH (IF EQUIPPED) BLK WIRE BLU WIRE BRN WIRE BSM OFF IND BSM OFF SWITCH (IF EQUIPPED) C-05 C-19 C-20 C-21 C-52 C-54 CLUSTER SWITCH COMPUTER DATA LINES SYSTEM DSC OFF SWITCH INSTRUMENT CLUSTER JOINT BOX 1 LDWS SWITCH LEFT BSM CONTROL MODULE LEFT BSM INDICATOR LIGHT LEFT POWER OUTER MIRROR LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE METER 1 FUSE MICROCOMPUTER NCA WIRE PNK WIRE PNK/BLK WIRE RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED RIGHT BSM CONTROL MODULE RIGHT BSM INDICATOR LIGHT RIGHT END OF DASH) RIGHT POWER OUTER MIRROR TPMS SET SWITCH (IF EQUIPPED) VIO WIRE WHT WIRE YEL WIRE
