Courtesy lamps circuit for Mazda 3 BM (2013-2016)

BLK WIRE BLU WIRE BRN WIRE C-08 C-18 C-20 C-21 C-22 C-23 CARGO COMPARTMENT LIGHT (HATCHBACK) CONDENSER DOOR FRONT MAP LIGHT GRN WIRE GRY WIRE GRY/RED WIRE HATCHBACK HOT AT ALL TIMES J/C C-39 LEFT "C" PILLAR) LEFT FRONT DOOR LATCH, LOCK ACTUATOR LEFT REAR DOOR LATCH, LOCK ACTUATOR LEFT VANITY MIRROR ILLUMINATION (IF EQUIPPED) OFF ORG/ WIRE RBCM REAR MAP LIGHT RED WIRE RELAY & FUSE BLOCK RIGHT END OF DASH) RIGHT FRONT DOOR LATCH, LOCK ACTUATOR RIGHT REAR DOOR LATCH, LOCK ACTUATOR RIGHT VANITY MIRROR ILLUMINATION (IF EQUIPPED) ROOM FUSE SEDAN TAN WIRE TRUNK COMPARTMENT LIGHT W/ DUAL LIGHT TYPE W/ SINGLE LIGHT TYPE W/O REAR MAP LIGHT W/ REAR MAP LIGHT WHT WIRE YEL WIRE
