Rear body control module circuit for Mazda 3 BM (2013-2016)
Rear body control module circuit
BLK WIRE
BLU WIRE
BRN WIRE
C-05
C-08
C-52
C-55
COMPUTER DATA LINES SYSTEM
D LOCK FUSE
DOOR LOCKS, ANTI-THEFT SYSTEMS
FRONT BODY CONTROL MODULE CIRCUIT
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
JOINT BOX 1 (LEFT KICK PANEL)
LT BLU WIRE
LT GRN WIRE
METER 1 FUSE
MIRRORS, EXTERIOR LIGHTS SYSTEMS
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER WINDOWS SYSTEM
R WIPER FUSE
RBCM
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
ROOM FUSE
TAN WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
