Automatic a/c circuit, single control for Mazda 3 BM (2013-2016)

Automatic a/c circuit, single control (1 of 2)

3 Mazda BM (2013-2016): Automatic a/c circuit, single control (1 of 2)

Get access

AIR FLOW MODE ACTUATOR AIR INTAKE ACTUATOR AIR MIX ACTUATOR BLK WIRE BLOWER FAN CONTROLLER BLOWER MOTOR BLOWER RELAY (HEATER) BLU WIRE BRN WIRE C-04 C-33 C-34 CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM EVAPORATOR TEMPERATURE SENSOR GRN WIRE GRY WIRE HEATER FUSE HOT AT ALL TIMES J/B 2 J/C 10 J/C C-36 LT BLU WIRE LT GRN WIRE PASSENGER COMPARTMENT TEMPERATURE SENSOR PNK WIRE RED WIRE RELAY & FUSE BLOCK ROOM FUSE SOLAR RADIATION SENSOR TAN WIRE VIO WIRE WHT WIRE YEL WIRE

Automatic a/c circuit, single control (2 of 2)

3 Mazda BM (2013-2016): Automatic a/c circuit, single control (2 of 2)

Get access

A/C FUSE A/C RELAY ADD FAN GE FUSE AMBIENT TEMPERATURE SENSOR BLK WIRE BLU WIRE BRN WIRE C-01 COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY 1 COOLING FAN RELAY 2 COOLING FAN RELAY 3 ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 FAN GE FUSE FBCM GRN WIRE GRY WIRE HAZARD FUSE HOT AT ALL TIMES HOT W/ MAIN RELAY ENERGIZED J/C C-32 JC-01 LT GRN WIRE MAGNETIC CLUTCH PCM (LEFT REAR OF ENGINE COMPT) PNK WIRE RED WIRE REFRIGERANT PRESSURE SENSOR RELAY & FUSE BLOCK TAN WIRE VIO WIRE WHT WIRE
