Car Wiring Diagrams for Mazda 3 BM (2013-2016) - Wiring diagrams commander switch

Wiring diagram commander switch (1 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (1 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-323 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GPS ANTENNA GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE NCA WIRE PNK WIRE REAR MOUNT CAMERA RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/ bose (1 of 5) -> COMMANDER SWITCH

Wiring diagram commander switch (2 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (2 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-323 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE (FRONT CENTER OF HEADLINER) NCA WIRE PNK PNK WIRE PNK WIRE RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Navigation circuit, with bose (1 of 5) -> COMMANDER SWITCH

Wiring diagram commander switch (3 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (3 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-218 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE (FRONT CENTER OF HEADLINER) NCA WIRE PNK PNK WIRE PNK WIRE RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Navigation circuit, without bose (1 of 3) -> COMMANDER SWITCH

Wiring diagram commander switch (4 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (4 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-218 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE NCA WIRE PNK WIRE REAR MOUNT CAMERA RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/o bose (1 of 3) -> COMMANDER SWITCH

Wiring diagram commander switch (5 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (5 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-323 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GPS ANTENNA GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE NCA WIRE PNK WIRE REAR MOUNT CAMERA RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/ bose (1 of 5) -> COMMANDER SWITCH

Wiring diagram commander switch (6 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (6 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-323 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE (FRONT CENTER OF HEADLINER) NCA WIRE PNK PNK WIRE PNK WIRE RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Radio circuit, with bose (1 of 5) -> COMMANDER SWITCH

Wiring diagram commander switch (7 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (7 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-218 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE (FRONT CENTER OF HEADLINER) NCA WIRE PNK PNK WIRE PNK WIRE RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Radio circuit, without bose with center display (1 of 3) -> COMMANDER SWITCH

Wiring diagram commander switch (8 of 8)

Wiring diagram commander switch for Mazda 3 BM (2013-2016) (8 of 8)

Get lifetime access to Mazda 3 BM (2013-2016)

0920-218 AUXILIARY JACK/SD CARD SLOT HUB/USB PORT BLK WIRE BLU WIRE BRN WIRE C-09 C-13 C-16 COMMANDER SWITCH COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT GRN WIRE GRY WIRE INTERIOR LIGHTS LT BLU WIRE MICROPHONE NCA WIRE PNK WIRE REAR MOUNT CAMERA RED WIRE SEDAN HATCHBACK SYSTEM WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/o bose w/ center display (1 of 3) -> COMMANDER SWITCH

Mazda 3 BM (2013-2016) commander switch Wiring diagrams

Wiring diagram commander switch (1 of 8)

List of components:

Wiring diagram commander switch (2 of 8)

List of components:

Wiring diagram commander switch (3 of 8)

List of components:

Wiring diagram commander switch (4 of 8)

List of components:

Wiring diagram commander switch (5 of 8)

List of components:

Wiring diagram commander switch (6 of 8)

List of components:

Wiring diagram commander switch (7 of 8)

List of components:

Wiring diagram commander switch (8 of 8)

List of components:
