Mazda 3 BM (2013-2016) auxiliary jack/usb port Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary jack/usb port, in which he is found in the car Mazda 3 BM (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
auxiliary jack/usb port wiring diagram (1 of 2)
0920-111
0920-112
ANTENNA AMP
AUDIO 1 FUSE
AUDIO 2 FUSE
AUDIO UNIT
AUXILIARY JACK/USB PORT
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-14
C-51
C-53
CD PLAYER (IF EQUIPPED)
CENTER ROOF ANTENNA
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INTERIOR LIGHTS
JOINT BOX 1 (LEFT KICK PANEL)
LINES SYSTEM COMPUTER DATA
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
RED WIRE
RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
ROOM FUSE
SEDAN
SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without bose without center display (1 of 3) -> AUXILIARY JACK/USB PORT
auxiliary jack/usb port wiring diagram (2 of 2)
