Tire pressure monitoring circuit, w/o advanced keyless entry & start system for Mazda 3 BL facelift (2011-2013)
Tire pressure monitoring circuit, w/o advanced keyless entry & start system
B A D E
BCM
BLK WIRE
BRN WIRE
BUZZER
C-02 AI
C-03
COMPUTER DATA LINES SYSTEM
ESCL FUSE
FUSE BLOCK
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C C-44
J/C C-45
J/C C-47
KEYLESS RECEIVER/ TPMS CONTROL MODULE
METER FUSE
MICROCOMPUTER
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY & FUSE BLOCK
ROOM FUSE
TPMS IND TRIPMETER SWITCH
WHT WIRE
YEL WIRE
