Mazda 3 BL facelift (2011-2013) instrument wiper/ cluster washer system system Wiring diagram
This page shows the only wiring diagram for the component.instrument wiper/ cluster washer system system, which is found in the car Mazda 3 BL facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument wiper/ cluster washer system system (1 of 1)
ABS IG FUSE
ACCESSORY SOCKET
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
AUDIO FUSE
BLK WIRE
BLU WIRE
BODY EXTERIOR COMPUTER LIGHTS SYSTEM SYSTEM
BRN WIRE
C-03
ENG FUSE
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, STARTING/ CHARGING SYSTEMS
FOG FUSE
FROM TNS RELAY (DIAGRAM 1 OF 2)
FRONT
FUSE
FUSE BLOCK
GRY WIRE
HEADLIGHTS SYSTEM
HEATER FUSE
HORN FUSE
HORN RELAY (HORN)
IGNITION SWITCH
INSTRUMENT WIPER/ CLUSTER WASHER SYSTEM SYSTEM
J/C C-43
J/C C-43 (FRONT OF CENTER CONSOLE)
J/C C-47
J/C C-51 (CENTER LEFT OF DASH)
J/C C-52
LT BLU WIRE
LT GRN WIRE
METER FUSE
MIRROR CIGAR FUSE FUSE
MIRRORS HEADLIGHTS, SYSTEM WIPER/WASHER ANTI- SYSTEMS THEFT SYSTEM
MIRRORS SHIFT SYSTEM INTERLOCK SYSTEM
NAVIGATION SYSTEM
OFF
ORG/ WIRE
P WIND FUSE
PNK WIRE
POWER AIR TOPS CONDITIONING SYSTEM SYSTEM
POWER WINDOWS SYSTEM
R WIPER FUSE F WIPER FUSE
RED WIRE
RELAY & FUSE BLOCK
RUN WIRE
SAS FUSE AFS FUSE
SEATS SYSTEM
SOUND SYSTEMS
STARTER RELAY (STARTER)
STARTING/ CHARGING SYSTEM
STOP FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
TRANS- WARNING INSTRUMENT MISSIONS SYSTEMS CLUSTER SYSTEM SYSTEM
VIO WIRE
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, without advanced keyless entry & start system (2 of 2) -> INSTRUMENT WIPER/ CLUSTER WASHER SYSTEM SYSTEM
