Mazda 3 BL facelift (2011-2013) exterior lights, starting/ charging systems Wiring diagrams
This page contains all the electrical diagrams for the component. exterior lights, starting/ charging systems, in which he is found in the car Mazda 3 BL facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram exterior lights, starting/ charging systems (1 of 2)
ABS IG FUSE
ACCESSORY SOCKET
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
AUDIO FUSE
BLK WIRE
BLU WIRE
BODY EXTERIOR COMPUTER LIGHTS SYSTEM SYSTEM
BRN WIRE
C-03
ENG FUSE
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, STARTING/ CHARGING SYSTEMS
FOG FUSE
FROM TNS RELAY (DIAGRAM 1 OF 2)
FRONT
FUSE
FUSE BLOCK
GRY WIRE
HEADLIGHTS SYSTEM
HEATER FUSE
HORN FUSE
HORN RELAY (HORN)
IGNITION SWITCH
INSTRUMENT WIPER/ CLUSTER WASHER SYSTEM SYSTEM
J/C C-43
J/C C-43 (FRONT OF CENTER CONSOLE)
J/C C-47
J/C C-51 (CENTER LEFT OF DASH)
J/C C-52
LT BLU WIRE
LT GRN WIRE
METER FUSE
MIRROR CIGAR FUSE FUSE
MIRRORS HEADLIGHTS, SYSTEM WIPER/WASHER ANTI- SYSTEMS THEFT SYSTEM
MIRRORS SHIFT SYSTEM INTERLOCK SYSTEM
NAVIGATION SYSTEM
OFF
ORG/ WIRE
P WIND FUSE
PNK WIRE
POWER AIR TOPS CONDITIONING SYSTEM SYSTEM
POWER WINDOWS SYSTEM
R WIPER FUSE F WIPER FUSE
RED WIRE
RELAY & FUSE BLOCK
RUN WIRE
SAS FUSE AFS FUSE
SEATS SYSTEM
SOUND SYSTEMS
STARTER RELAY (STARTER)
STARTING/ CHARGING SYSTEM
STOP FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
TRANS- WARNING INSTRUMENT MISSIONS SYSTEMS CLUSTER SYSTEM SYSTEM
VIO WIRE
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, without advanced keyless entry & start system (2 of 2) -> EXTERIOR LIGHTS, STARTING/ CHARGING SYSTEMS
Wiring diagram exterior lights, starting/ charging systems (2 of 2)
ABS IG FUSE
ACCESSORY SOCKET (FRONT)
AFS FUSE
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS
ANTI-THEFT SYSTEM
AUDIO FUSE
BLK WIRE
BLU WIRE
BODY COMPUTER SYSTEM
BRN WIRE
C-03
CIGAR FUSE
ENG FUSE
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, STARTING/ CHARGING SYSTEMS
F WIPER FUSE
FOG FUSE
FROM TNS RELAY (DIAGRAM 1 OF 2)
FUSE BLOCK
GRY WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS, WIPER/WASHER SYSTEMS
HEATER FUSE
HORN FUSE
HORN RELAY (HORN)
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
J/C C-43
J/C C-47
J/C C-51
J/C C-52
LT BLU WIRE
LT GRN WIRE
METER FUSE
MIRROR FUSE
MIRRORS SYSTEM
NAVIGATION SYSTEM
OFF
ORG/ WIRE
P WIND FUSE
PNK WIRE
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
R WIPER FUSE
RED WIRE
RELAY & FUSE BLOCK
RUN WIRE
SAS FUSE
SEATS SYSTEM
SHIFT INTERLOCK SYSTEM
SOUND SYSTEMS
STARTER RELAY (STARTER)
STARTING/ CHARGING SYSTEM
STOP FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANS- MISSIONS SYSTEM
VIO WIRE
WARNING SYSTEMS
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, w/o advanced keyless entry & start system (2 of 2) -> EXTERIOR LIGHTS, STARTING/ CHARGING SYSTEMS
