Mazda 3 BL facelift (2011-2013) energized hot in on Wiring diagram
This page shows the only wiring diagram for the component.energized hot in on, which is found in the car Mazda 3 BL facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram energized hot in on (1 of 1)
BLK WIRE
BLU WIRE
C-04
C-13
C-17
C-33
ENERGIZED HOT IN ON
FUSE BLOCK
GRN WIRE
GRY WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT) SEAT WARM FUSE
J/C C-51
J/C C-51 (CENTER LEFT OF DASH)
LEFT SEAT WARMER SWITCH
LEFT SEAT WARMER UNIT
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
RED WIRE
RELAY & FUSE BLOCK
RIGHT SEAT WARMER SWITCH
RIGHT SEAT WARMER UNIT
SEAT BACK FILAMENT
SEAT WARM FUSE
WHT WIRE
Go to component -> Heated seats circuit -> ENERGIZED HOT IN ON
