Mazda 3 BL facelift (2011-2013) electronic power steering system Wiring diagrams

This page contains all the electrical diagrams for the component. electronic power steering system, in which he is found in the car Mazda 3 BL facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram electronic power steering system (1 of 4)

Wiring diagram electronic power steering system for Mazda 3 BL facelift (2011-2013) (1 of 4)

Get lifetime access to Mazda 3 BL facelift (2011-2013)

2.0L 2.3L TURBO, 2.5L 2.3L TURBO SKYACTIV-G 2.0L A/C MAG FUSE A/C RELAY (A/C) ABS FUSE ACCESSORY SOCKET (REAR) ANTI-LOCK BRAKES SYSTEM AT MAIN RELAY (AT MAIN) BATTERY BLK WIRE BLK/RED WIRE BLOWER RELAY (HEATER) BLU WIRE BOSE 2 FUSE BRN WIRE C-03 C-18 COMPUTER DATA LINES, EXTERIOR LIGHTS SYSTEMS COOLING FANS SYSTEM D LOCK FUSE DOOR LOCKS SYSTEM DRL RELAY (DRL) DSC FUSE EHPAS FUSE ELECTRONIC POWER STEERING SYSTEM ENG BAR FUSE ENG INJ FUSE ENG MAIN FUSE ENG+B FUSE ENGINE CONTROLS SYSTEM ENGINE CONTROLS, TRANSMISSIONS SYSTEMS ESCL FUSE ETV FUSE EVVT FUSE EVVT RELAY FROM DSC FUSE (DIAGRAM 1 OF 2) FROM RELAY & FUSE BLOCK (DIAGRAM 1 OF 2) FUEL INJECTOR RELAY (INJ) FUEL PUMP FUSE FUEL PUMP RELAY FUSE BLOCK GRN WIRE GRY WIRE H/L HI FUSE HAZARD FUSE HEADLIGHT RELAY (HI) HEADLIGHT RELAY (LO) HEATER FUSE ILLUMI FUSE INJ FUSE INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT GRN WIRE MAIN FUSE MAIN RELAY (EGI MAIN) ORG/ WIRE OUTLET FUSE P SEAT FUSE P WIND FUSE PNK WIRE POWER TOPS SYSTEM POWER WINDOWS SYSTEM R DEF FUSE REAR WINDOW DEFROSTER RELAY (R DEF) RED WIRE RELAY & FUSE BLOCK ROOM FUSE SEAT WARM FUSE SEATS SYSTEM SOUND SYSTEMS STARTER FUSE STARTING/ CHARGING SYSTEM SUNROOF FUSE SUPPLEMENTAL RESTRAINTS SYSTEM SWS FUSE TAIL FUSE TCM FUSE TNS RELAY (TAIL) TO FOG FUSE (DIAGRAM 2 OF 2) TO MAIN RELAY (EGI MAIN) (DIAGRAM 1 OF 2) TO TCM FUSE (DIAGRAM 1 OF 2) TRANSMISSIONS SYSTEM VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power distribution circuit, w/ advanced keyless entry & start system (1 of 2) -> ELECTRONIC POWER STEERING SYSTEM

Wiring diagram electronic power steering system (2 of 4)

Wiring diagram electronic power steering system for Mazda 3 BL facelift (2011-2013) (2 of 4)

Get lifetime access to Mazda 3 BL facelift (2011-2013)

2.0L 2.3L TURBO, 2.5L 2.3L TURBO SKYACTIV-G 2.0L A/C MAG FUSE A/C RELAY (A/C) ABS FUSE ACCESSORY SOCKET ANTI-LOCK BRAKES SYSTEM AT MAIN RELAY (AT MAIN) BATTERY BLK WIRE BLK/RED WIRE BLOWER RELAY (HEATER) BLU LT WIRE BLU WIRE BOSE 2 FUSE BRN WIRE C-03 C-18 COMPUTER DATA LINES, EXTERIOR LIGHTS SYSTEMS COOLING FANS SYSTEM DOOR LOCKS SYSTEM DRL RELAY HEADLIGHT RELAY (LO) (DRL) (IF EQUIPPED) DSC FUSE EHPAS FUSE ELECTRONIC POWER STEERING SYSTEM ENG ENG MAIN FUSE ENG+B FUSE ENGINE CONTROLS SYSTEM ESCL FUSE ETV FUSE EVVT FUSE EVVT RELAY FROM DSC FUSE (DIAGRAM ENG INJ ENG BAR 1 OF 2) FROM RELAY & FUSE BLOCK (DIAGRAM 1 OF 2) FUEL INJECTOR RELAY FUEL PUMP FUSE FUEL PUMP RELAY FUSE FUSE BLOCK FUSE FUSE FUSE FUSE FUSE GRN WIRE GRN/ LT WIRE GRY WIRE H/L HI FUSE HAZARD FUSE HEADLIGHT RELAY (HI) HEATER FUSE ILLUMI FUSE INJ + INJ FUSE INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT GRN WIRE MAIN FUSE STARTER FUSE MAIN RELAY (EGI MAIN) ORG/ WIRE OUTLET FUSE P SEAT D LOCK FUSE FUSE P WIND FUSE PNK WIRE POWER TOPS SYSTEM POWER WINDOWS SYSTEM R DEF FUSE REAR REAR WINDOW DEFROSTER RELAY (R DEF) RED WIRE RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT) ROOM FUSE SEAT WARM FUSE SEATS DOOR SYSTEM LOCKS SYSTEM SEATS SYSTEM SOUND SYSTEMS STARTING/ CHARGING SYSTEM SUNROOF FUSE SUPPLEMENTAL ENGINE RESTRAINTS CONTROLS, SYSTEM TRANSMISSIONS SYSTEMS SWS FUSE TAIL FUSE TCM FUSE TNS RELAY (TAIL) TO FOG FUSE (DIAGRAM 2 OF 2) TO MAIN RELAY (EGI MAIN) (DIAGRAM 1 OF 2) TO TCM FUSE (DIAGRAM 1 OF 2) TRANSMISSIONS SYSTEM VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power distribution circuit, with advanced keyless entry & start system (1 of 2) -> ELECTRONIC POWER STEERING SYSTEM

Wiring diagram electronic power steering system (3 of 4)

Wiring diagram electronic power steering system for Mazda 3 BL facelift (2011-2013) (3 of 4)

Get lifetime access to Mazda 3 BL facelift (2011-2013)

2.0L 2.3L TURBO, 2.5L 2.3L TURBO SKYACTIV-G 2.0L A/C MAG FUSE A/C RELAY (A/C) ABS FUSE ACCESSORY SOCKET ANTI-LOCK BRAKES SYSTEM AT MAIN RELAY (AT MAIN) BATTERY BLK WIRE BLK/RED WIRE BLOWER RELAY (HEATER) BLU WIRE BOSE 2 FUSE BRN WIRE C-03 C-18 COMPUTER DATA LINES, EXTERIOR LIGHTS SYSTEMS COOLING FANS SYSTEM D LOCK P SEAT FUSE FUSE DRL RELAY HEADLIGHT RELAY (LO) (DRL) (IF EQUIPPED) DSC FUSE EHPAS FUSE ELECTRONIC POWER STEERING SYSTEM ENG ENG MAIN FUSE ENG+B FUSE ENGINE CONTROLS SYSTEM ENGINE CONTROLS, TRANSMISSIONS SYSTEMS ESCL FUSE ETV FUSE EVVT FUSE EVVT RELAY FROM DSC FUSE (DIAGRAM 1 OF 2) ENG BAR ENG INJ FROM RELAY & FUSE BLOCK (DIAGRAM 1 OF 2) FUEL PUMP FUSE FUEL PUMP RELAY FUSE FUSE BLOCK FUSE FUSE FUSE FUSE FUSE GRN WIRE GRN/ LT WIRE GRY WIRE H/L HI FUSE HAZARD FUSE HEADLIGHT RELAY (HI) HEATER FUSE ILLUMI FUSE INJ + INJ FUSE INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT GRN WIRE MAIN FUSE STARTER FUSE MAIN RELAY (EGI MAIN) ORG/ WIRE OUTLET FUSE P WIND FUSE PNK WIRE POWER TOPS SYSTEM POWER WINDOWS SYSTEM R DEF FUSE SUNROOF FUSE FUSE REAR REAR WINDOW DEFROSTER RELAY (R DEF) RED WIRE RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT) ROOM FUSE SEAT WARM FUSE SEATS DOOR SYSTEM LOCKS SYSTEM SEATS SYSTEM SOUND SYSTEMS STARTING/ CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM SWS FUSE TAIL FUSE TCM FUSE TNS RELAY (TAIL) TO FOG FUSE (DIAGRAM 2 OF 2) TO MAIN RELAY (EGI MAIN) (DIAGRAM 1 OF 2) TO TCM FUSE (DIAGRAM 1 OF 2) TRANSMISSIONS ENGINE SYSTEM CONTROLS SYSTEM VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power distribution circuit, without advanced keyless entry & start system (1 of 2) -> ELECTRONIC POWER STEERING SYSTEM
