Mazda 3 BL facelift (2011-2013) coil antenna Wiring diagrams
This page contains all the electrical diagrams for the component. coil antenna, in which he is found in the car Mazda 3 BL facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram coil antenna (1 of 3)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C-03
C-04
C-20
C-24
C-28
C-29
C-39
CENTER REAR OF LUGGAGE COMPT)
COIL ANTENNA
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
D LOCK FUSE
ENG+B FUSE
FUSE BLOCK
GRN WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
J/C C-43
J/C C-44
J/C C-47
J/C C-51
J/C C-53
KEY REMINDER SWITCH
KEYLESS BEEPER
KEYLESS CONTROL MODULE
LEFT "C" PILLAR)
LEFT FRONT EXTERIOR KEYLESS ANTENNA
LEFT FRONT OUTER HANDLE
LT BLU WIRE
LT GRN WIRE
MAIN RELAY
METER FUSE
MIRROR FUSE
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
REAR EXTERIOR KEYLESS ANTENNA
REAR INTERIOR KEYLESS ANTENNA
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
REQUEST SWITCH
REQUEST SWITCH (WAGON)
ROOM FUSE
SEDAN
STARTING/CHARGING SYSTEM
TRUNK LID LATCH, RELEASE ACTUATOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, w/ advanced keyless entry & start system (1 of 3) -> COIL ANTENNA
Wiring diagram coil antenna (2 of 3)
