Front wheel alignment (Unloaded)*1 [MZR 2.0, SKYACTIV-G 2.0, MZR 2.5]
| Item | Fuel gauge indication | ||||||
|---|---|---|---|---|---|---|---|
| Empty | 1/4 | 1/2 | 3/4 | Full | |||
| Maximum steering angle [Tolerance ±3°] | Inner | 41°00' | |||||
| Outer | 34°00' | ||||||
| Total toe-in | Tire [Tolerance ±4 {±0.2}] | (mm {in}) | 2 {0.08} | ||||
| Rim inner [Tolerance ±3 {±0.1}] | Vehicle equipped with 16 inch wheel: 1.3 {0.051} Vehicle equipped with 17 inch wheel: 1.4 {0.055} | ||||||
| (degree) | 0°11'±0°22' | ||||||
| Caster angle *2 (Reference value) [Tolerance ±1°] | 2°59' | 3°01' | 3°03' | 3°05' | 3°07' | ||
| Camber angle *2 (Reference value) [Tolerance ±1°] | 0°37' | 0°38' | |||||
| Steering axis inclination (Reference value) | 13°54' | 13°55' | 13°56' | ||||
* 1
Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
* 2
Difference between left and right must not exceed 1°30' .
Front wheel alignment (Unloaded)*1 [MZR 2.3 DISI Turbo]
| Item | Fuel gauge indication | ||||||
|---|---|---|---|---|---|---|---|
| Empty | 1/4 | 1/2 | 3/4 | Full | |||
| Maximum steering angle [Tolerance ±3°] | Inner | 36°00' | |||||
| Outer | 30°00' | ||||||
| Total toe-in | Tire [Tolerance ±4 {±0.2}] | (mm {in}) | 2 {0.08} | ||||
| Rim inner [Tolerance ±3 {±0.1}] | 1.5 {0.059} | ||||||
| (degree) | 0°11'±0°22' | ||||||
| Caster angle *2 (Reference value) [Tolerance ±1°] | 3°06' | 3°08' | 3°09' | 3°11' | 3°12' | ||
| Camber angle *2 (Reference value) [Tolerance ±1°] | 0°53' | 0°54' | |||||
| Steering axis inclination (Reference value) | 14°18' | 14°19' | 14°20' | ||||
* 1
Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
* 2
Difference between left and right must not exceed 1°30'.
Scheme 2
- Loosen the tie-rod end locknuts.
- Remove the steering gear boot clamp.
- Turn the tie rods. (Scheme 2): Turning Tie Rods Standard length L 13-31 mm {0.6-1.2 in}
- Turn the tie rods equally to provide the correct maximum steering angle.
- Tighten the tie-rod end locknuts. Tightening torque 79-108 N.m {8.1-11 kgf.m, 59-79 ft.lbf}
- Verify that the boot is not twisted, and install the boot clamp.
- Adjust the toe-in after adjusting the steering angle.
Total Toe-in Adjustment
- Loosen the locknut of the tie-rod end.
- Remove the rack boot clamp.
- Adjust the total toe-in by rotating each tie rod (left and right) in the opposite directions by the same amount respectively. NOTE: Toe angle changes by approx. 6 mm {0.2 in} per one rotation of the tie rod for one wheel. Each tie rod has a right-hand thread. When increasing the toe-in angle, rotate the right tie rod toward the front of the vehicle and rotate the left tie rod toward the rear of the vehicle by the same amount.
- Tighten the locknut of the tie-rod end. Tightening torque 79-108 N.m {8.1-11 kgf.m, 59-79 ft.lbf}
- Verify that the rack boot does not have any twisting and install the rack boot clamp.
Rear wheel alignment (Unloaded)*1 [MZR-2.0, SKYACTIV-G 2.0, MZR-2.5]
| Item | Fuel gauge indication | ||||||
|---|---|---|---|---|---|---|---|
| Empty | 1/4 | 1/2 | 3/4 | Full | |||
| Total toe-in | Tire [Tolerance ±4 {±0.2}] | (mm {in}) | 3 {0.1} | ||||
| Rim inner [Tolerance ±3 {±0.1}] | Vehicle equipped with 16 inch wheel: 1.9 {0.075} Vehicle equipped with 17 inch wheel: 2.0 {0.079} | ||||||
| (degree) | 0°16'±0°21' | ||||||
| Camber angle *2 (Reference value) [Tolerance ±1°] | 1°23' | 1°25' | 1°27' | 1°28' | 1°30' | ||
| Thrust angle [Tolerance ±0°48'] | 0° | ||||||
* 1
Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
* 2
Difference between left and right must not exceed 1°30'.
Rear wheel alignment (Unloaded)*1 [MZR-2.3 DISI Turbo]
| Item | Fuel gauge indication | ||||||
|---|---|---|---|---|---|---|---|
| Empty | 1/4 | 1/2 | 3/4 | Full | |||
| Total toe-in | Tire [Tolerance ±4 {±0.2}] | (mm {in}) | 3 {0.1} | ||||
| Rim inner [Tolerance ±3 {±0.1}] | 2.2 {0.087} | ||||||
| (degree) | 0°16'±0°21' | ||||||
| Camber angle *2 (Reference value) [Tolerance ±1°] | 1°35' | 1°36' | 1°38' | 1°39' | 1°41' | ||
| Thrust angle [Tolerance ±0°48'] | 0° | ||||||
* 1
Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.
* 2
Difference between left and right must not exceed 1°30'.
Scheme 3
- Loosen the installation nut of the adjusting cam bolt.
- Rotate the adjusting cam bolt in either direction to adjust the toe-in. (Scheme 3): Identifying Adjusting Cam Bolt Left wheel Right wheel Toe-out direction Clockwise Counterclockwise Toe-in direction Counterclockwise Clockwise
- Tighten the nut. Tightening torque 80-100 N.m {8.2-10 kgf.m, 60-73 ft.lbf}
