Car Wiring Diagrams for Cooling fan circuit for Mazda 3 BL (2008-2011)

2.0L CALIFORNIA, 2.3L CALIFORNIA 2.0L EXCEPT CALIFORNIA, 2.3L EXCEPT CALIFORNIA 2.0L EXCEPT CALIFORNIA 2.3L TURBO EXCEPT 2.3L TURBO BLK WIRE BLU WIRE BRN WIRE BRN/RED WIRE COOLING FAN MOTOR ENGINE COOLANT TEMPERATURE SENSOR (ON TOP REAR OF ENGINE) FAN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) FAN FUSE FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) HOT AT ALL TIMES NCA WIRE PCM (REAR OF ENGINE COMPT) PNK WIRE PNK/RED WIRE RED WIRE WHT WIRE WHT/RED WIRE
