Car Wiring Diagrams for Immobilizer circuit for Mazda 3 BL (2008-2011)

AP J-03 BLK WIRE BLU WIRE BUZZER COIL ANTENNA (ON IGNITION KEY CYLINDER) FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER J-01 J-03 METER FUSE MICROCOMPUTER OFF ORG/ WIRE PASSENGER JUNCTION BOX (PJB) (BEHIND RIGHT SIDE OF DASH) RED WIRE ROOM FUSE RUN WIRE SECURITY IND WHT WIRE YEL WIRE
