Mazda 3 BL (2008-2011) variable swirl shutter valve switch Wiring diagram
This page shows the only wiring diagram for the component.variable swirl shutter valve switch, which is found in the car Mazda 3 BL (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram variable swirl shutter valve switch (1 of 1)
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BRAKE SWITCH (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/GRN WIRE
DRIVE-BY-WIRE RELAY (ETV)
ENG +B FUSE
ENG BAR 1 FUSE
ENG BAR 2 FUSE
ENG BAR 3 FUSE
ENGINE FUSE
ETC FUSE
FUEL INJECTOR RELAY (INJECTOR)
FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
INJECTOR FUSE
J-01
J-05 PASSENGER JUNCTION BOX (PJB) (BEHIND RIGHT SIDE OF DASH)
MAIN RELAY (MAIN)
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VARIABLE SWIRL SHUTTER VALVE SWITCH
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Wiring diagram engine performance 2.3l turbo (1 of 4) -> VARIABLE SWIRL SHUTTER VALVE SWITCH
