Mazda 3 BL (2008-2011) preset mode switch switch wiring diagram
This page shows the only wiring diagram for the component.preset mode switch switch, which is found in the car Mazda 3 BL (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
preset mode switch switch wiring diagram (1 of 1)
0922-202 CLOCK SPRING (BELOW STEERING WHEEL)
0922-203
AUDIO CONTROL SWITCH
AUDIO UNIT
AUTO SCAN SWITCH
AUXILIARY JACK
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES FUSE, RELAY BOX (LEFT REAR OF ENGINE COMPT) ROOM FUSE
HOT IN ACC OR RUN
J-01
J-03 AA
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER (IF EQUIPPED)
MUTE SWITCH
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER JUNCTION BOX (PJB) (BEHIND RIGHT SIDE OF DASH)
PRESET MODE SWITCH SWITCH
RADIO FUSE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER (IF EQUIPPED)
SIRIUS SATELLITE RADIO UNIT
VOL+ SWITCH
W/ SIRIUS SATELLITE RADIO UNIT
W/O SIRIUS SATELLITE RADIO UNIT
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Radio circuit, with base without navigation -> PRESET MODE SWITCH SWITCH
