Mazda 3 BL (2008-2011) front fog light switch light switch Wiring diagram
This page shows the only wiring diagram for the component.front fog light switch light switch, which is found in the car Mazda 3 BL (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front fog light switch light switch (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BLU/ORG WIRE
DISCHARGE TYPE
FOG FUSE
FRONT FOG LIGHT RELAY (IN FUSE, RELAY BOX)
FRONT FOG LIGHT SWITCH LIGHT SWITCH
FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
HALOGEN TYPE
HEAD
HEAD FUSE
HEAD HIGH L FUSE
HEAD HIGH R FUSE
HEAD LOW L FUSE
HEAD LOW R FUSE
HEADLIGHT HIGH RELAY
HEADLIGHT LOW RELAY
HI LO FLASH- TO- PASS
HOT AT ALL TIMES
IGNITION SWITCH
J-01
J-01 AM
J-02
J-03
J-03 AP
J-03 J-04 AE
J-04 AS
LEFT DISCHARGE CONTROL MODULE
LEFT FRONT FOG LIGHT
LEFT LOW HEAD- LIGHT LEFT HIGH HEAD- LIGHT
LEFT LOW HEADLIGHT
LIGHT SWITCH/ FRONT FOG LIGHT SWITCH TNS OFF
MICROCOMPUTER
NCA WIRE
OFF
ORG/ WIRE
ORG/WHT WIRE
PASSENGER JUNCTION BOX (PJB) (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
RED WIRE
RIGHT DISCHARGE CONTROL MODULE
RIGHT FRONT FOG LIGHT
RIGHT HIGH HEAD- LIGHT
RIGHT LOW HEAD- LIGHT
RIGHT LOW HEADLIGHT
RUN WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, without drl -> FRONT FOG LIGHT SWITCH LIGHT SWITCH
