Car Wiring Diagrams for Defoggers circuit for Mazda 3 BK facelift (2006-2009)

A/C FUSE AD J-04 BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLU WIRE CLIMATE CONTROL UNIT DEFOG FUSE DOOR FILAMENT FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN J-01 J-01 AH J-05 LEFT HEATED OUTER MIRROR (IF EQUIPPED) M/DEF FUSE MICROCOMPUTER MIRROR HEATER NCA WIRE ORG/ WIRE PASSENGER JUNCTION BOX (BEHIND RIGHT SIDE OF DASH) PNK WIRE REAR WINDOW DEFROSTER RELAY RED WIRE RIGHT HEATED OUTER MIRROR YEL WIRE
