Car Wiring Diagrams for Immobilizer circuit for Mazda 3 BK facelift (2006-2009)

AC J-03 AP J-03 BLK WIRE COIL ANTENNA (ON IGNITION KEY CYLINDER) GRN WIRE GRY WIRE HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER METER FUSE MICROCOMPUTER OFF ORG/ WIRE PASSENGER JUNCTION BOX (BEHIND RIGHT SIDE OF DASH) RED WIRE RUN WIRE WHT WIRE YEL WIRE
