Mazda 3 BK (2003-2006) left low head- light left hid control unit Wiring diagram
This page shows the only wiring diagram for the component.left low head- light left hid control unit, which is found in the car Mazda 3 BK (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left low head- light left hid control unit (1 of 1)
BEAM SWITCH
BLK WIRE
BLU WIRE
BLU/ORG WIRE
FOG FUSE
FRONT FOG LIGHT RELAY (IN FUSE, RELAY BLOCK)
FRONT FOG LIGHT SWITCH
FUSE, RELAY BLOCK (LEFT REAR OF ENGINE COMPT)
GRN WIRE
HALOGEN TYPE
HEAD FUSE
HEAD HIGH L FUSE
HEAD HIGH R FUSE
HEAD LOW L FUSE
HEAD LOW R FUSE
HEAD TNS OFF AUTO
HEADLIGHT HIGH RELAY
HEADLIGHT LEVELING SWITCH
HEADLIGHT LOW RELAY
HEADLIGHT SWITCH
HI LO FLASH- TO- PASS
HID TYPE
HOT AT ALL TIMES
IGNITION SWITCH
J-01
J-01 AM
J-02
J-03
J-03 AL
J-03 AP
J-04
J-04 J-03 AS AE
LEFT FRONT FOG LIGHT
LEFT HIGH HEAD- LIGHT
LEFT LOW HEAD- LIGHT LEFT HID CONTROL UNIT
LEFT LOW HEADLIGHT
LOCK
MICROCOMPUTER
ORG/ WIRE
ORG/WHT WIRE
PASSENGER JUNCTION BOX (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT FOG LIGHT
RIGHT HID CONTROL UNIT
RIGHT HIGH HEAD- LIGHT RIGHT LOW HEAD- LIGHT
RIGHT LOW HEADLIGHT
RUN WIRE
WHT WIRE
WITH AUTO LIGHT SYSTEM
WITH HEADLIGHT MANUAL LEVELING SYSTEM
YEL WIRE
Go to component -> Headlights circuit, without drl -> LEFT LOW HEAD- LIGHT LEFT HID CONTROL UNIT
